Siglent SDS2000 Power analysis option

With this software option power-analysis can be added to the functionality of the Siglent SDS2000 scopes.

With this option the following functions are added to the device.

• Measure switching loss and conduction loss at the switching device.
• Analyze dI/dt slew rate.
• Automate oscilloscope setup for ripple measurements.
• Perform pre-compliance testing to IEC 61000-3-2 standards.
• Analysis line power with total harmonic distortion, true power, apparent power, power factor tests.
• Measure output noise.
• Analysis modulation using the on-time information of a Pulse Width Modulation (PWM) signal.
• Measure how well a circuit rejects ripple coming from the input power supply at various frequencies with the Power Supply Rejection Ratio (PSRR) measurement.
