Owon AG2052F function generator with Power Amplifier
Détails
The AG2000 series function generators by Owon are high quality 2 channel generators with a high value. With the 250MS/s sample rate and a bandwidth up to 60MHz these devices can be used for a wide array of purposes. The 14 bits vertical resolution and frequency precision up to 1µHz allow for an accurate waveform output.
The 3.9" 480x320 TFT colour screen allows for easy control of the device. The generator features a frequency counter that can measure up to 200MHz.
The device has 45 standard waveforms pre-programmed, amongst which are for example Sine, Square, Pulse, Ramp, and Noise.
The AG2000 series can be connected to a computer using the USB or the RS232 connection. With the bundled software the user can add custom functions with up to 1 million points. These functions can be stored in one of the 26 available memory slots.
The devices in the AG2000 series are capable of signal modulation, specifically they are capable of: AM, FM, PM en FSK modulation
Models
The devices in the AG2000 series differ mainly in bandwidth. The key differences are displayed in the table below.
| Model | AG2052F | AG2062F |
|---|---|---|
| Maximal output frequency | 50 MHz | 60 MHz |
Specifications
| Maximal sample rate | 250 MS/s |
| Maximal function length | 1Mpts |
| Modulation | Yes |
| Vertical Resolution | 14 bits |
| Display | 3,9" TFT, 480x320 pixels |
| Built in functions | i.a. Sine, Square, Ramp, Pulse, Noise, Arbitrary, DC Check the specification-sheet for more info. |
| Output impedance | 50 Ω |
| Frequency range | 1 μHz - 50 MHz |
| Amplitude | 1m Vpp - 10 Vpp (50Ω), 1m Vpp - 20 Vpp (high impedance) |
| Channels | 2 |
| Connectivity | USB 2.0 type A, USB type B, RS232 |
| Weight (without box) | 3.0 Kg |
| Dimensions | 235 × 110 × 295 mm |
For more information check the specification-sheet for a more detailed overview of specifications.
Accessoires
Function generators in the Owon AG2000 come bundled with:
- Quick-start manual
- USB cable
- Power cord
- CD with Software (Windows XP, Vista, 7)
The manual for these devices can be found here.
