SNT-1307 switching power supply
Nous travaillons à la traduction de cette page. Veuillez nous excuser pour le désagrément.
Détails
This switching power supply has a power of 83 Watt. It is an energy-efficient power supply that meets the criteria of ecologically sustainable electronic products. The unit has a stable metallic casing with a protective contact plug and ventilation slots. The power supply works with a fanless special technology and is suitable for the operation of the CB mobile radio and amateur radio equipment in the inner area.
Model overview
Besides this model, we also sell a more powerful model. The main differences are shown in the table below..
| Model | SNT-1307 | SNT-1322 |
|---|---|---|
| Power | 83 watt | 304 watt |
| Output current | 6 A | 20 A |
| Fuse | 1A | 2A |
| Dimensions | 110 x 80 x 200 mm | 115 x 115 x 255 mm |
| Weight | 1.0 kg | 1.3 kg |
| Price |
Specifications
| Output voltage | 13.8 V |
| Input current | 230 V / 50 Hz |
| Ripple | < 100 mV p-p |
| Short-circuit protection | yes |
| Overload protection | yes |
Accessories
The power supply comes with the following accessories:
- Power cord
- Manual
Téléchargements
| SNT-1307 Compact manual (German) |  (231.5 KB) | Télécharger |
| SNT-1307 Manual (German) | (472.33 KB) | Télécharger |
